Specifications


Voltage DC




Range
0 - 600.0 V


Accuracy
1% ± 5 counts






Voltage AC




Range
0 - 600.0 V


Accuracy
1% ± 5 counts (50/60 Hz)


AC Response
True-rms






Current AC




Range
0 - 600.0 A


Accuracy
2% ± 5 counts (50/60 Hz)


Crest Factor(50/60 Hz)
2.4 @ 500A, 2.0 @ 600A, add 2% for CF>2


AC Response
True-rms






Resistance




Range
0 - 600.0 Ω, 6001 - 6000 Ω


Accuracy
1.5% ± 5 counts






Inrush Current




Integration Time
100 ms






Continuity

















Environmental Specifications


Operating Temperature





-10 °C to +50 °C, -14 °F to 122 °F






Storage Temperature





-40?C to +60?C, -22 °F to 140 °F






Operating Altitude





2,500 meters max, 6,500 ft max






Temperature De-rating





Add 0.1 x specified accuracy for each ?C above 28?C or below 18?C (above 82.4°F or below 64.4°F)











Safety Specifications


Safety Rating





IEC 1010-2-032, 600V CAT II

The T6-1000 Pro is a professional-grade electrical tester. It is designed to make troubleshooting a wide range of electrical systems easier. The T6-1000 Pro features FieldSense technology, which allows users to measure voltage and current without test leads. Its 1000V range and continuity check offers added versatility and convenience for a range of environments and tasks. Additionally, it provides resistance measurement up to 100.0 kΩ. For safety and accurate readings, this tester has an open fork for easy sliding of wires and a well-lit LED screen for clear readings. It is most commonly used by electricians and electrical maintenance personnel
